Our aluminium lugs offer lightweight, durable, and cost-effective solutions for reliable electrical connections. Ideal for power distribution, automotive, and renewable energy applications, they ensure excellent conductivity and easy installation.
Features of aluminium lugs
Superior Conductivity: Ensures efficient power transfer, reducing energy loss and improving system performance.
Corrosion Resistance: Provides long-lasting durability, even in harsh environments, minimizing maintenance costs.
Lightweight Design: Eases handling and installation, saving time and labor costs for technicians.
Versatile Compatibility: Suitable for a wide range of applications, including power distribution, automotive, and renewable energy sectors.
Cost-Effective Solution: Offers high performance at a competitive price, maximizing value for your investment.
Application of aluminium lugs
Power Distribution Systems: Providing reliable connections between cables and electrical equipment, essential for stable power supply.
Telecommunications: Ensuring stable signal transmission and connectivity in communication networks.
Renewable Energy Systems: Supporting solar and wind power installations by facilitating efficient energy transfer.
Automotive Industry: Used in vehicles for robust electrical connections, enhancing performance and safety.
Marine Applications: Providing durable connections in harsh marine environments, ensuring reliability and longevity.
Industrial Machinery: Ensuring efficient power distribution and connectivity in various industrial equipment.
Parameter
Type | Hole diameterΦ (mm) | Inner diameter (mm) | Outer diameter (mm) | Width (mm) | Length (mm) |
SC1.5-4 | 4 | 2.5 | 3.5 | 6.5 | 18 |
SC1.5-5 | 5 | 2.5 | 3.5 | 7.5 | 18 |
SC1.5-6 | 6 | 2.5 | 3.5 | 9 | 18 |
SC2.5-4 | 4 | 2.8 | 4 | 6.5 | 19.5 |
SC2.5-5 | 5 | 2.8 | 4 | 7.2 | 19.5 |
SC2.5-6 | 6 | 2.8 | 4 | 9.5 | 19.5 |
SC4-4 | 4 | 3.7 | 5 | 7 | 20 |
SC4-5 | 5 | 3.7 | 5 | 7.5 | 20 |
SC4-6 | 6 | 3.7 | 5 | 11 | 20 |
SC4-8 | 8 | 3.7 | 5 | 11 | 20 |
SC6-5 | 5 | 4.8 | 6 | 8 | 24.5 |
SC6-6 | 6 | 4.8 | 6 | 9 | 24.5 |
SC6-8 | 8 | 4.8 | 6 | 10.5 | 24.5 |
SC10-6 | 6 | 5.2 | 6.5 | 10 | 26 |
SC10-8 | 8 | 5.2 | 6.5 | 11.5 | 26 |
SC10-10 | 10 | 5.2 | 6.5 | 14.2 | 26 |
SC16-6 | 6 | 6.2 | 8 | 12 | 31 |
SC16-8 | 8 | 6.2 | 8 | 12 | 31 |
SC16-10 | 10 | 6.2 | 8 | 13 | 31 |
SC16-12 | 12 | 7.2 | 9 | 16.8 | 36 |
SC25-6 | 6 | 7.2 | 9 | 13.2 | 33 |
SC25-8 | 8 | 7.2 | 9 | 13.2 | 33 |
SC25-10 | 10 | 7.2 | 9 | 13.2 | 33 |
SC25-12 | 12 | 7.2 | 9 | 17 | 33 |
SC35-6 | 6 | 8.5 | 10.5 | 15.5 | 37.2 |
SC35-8 | 8 | 8.5 | 10.5 | 15.5 | 37.2 |
SC35-10 | 10 | 8.5 | 10.5 | 15.5 | 37.2 |
SC35-12 | 12 | 8.5 | 10.5 | 15.5 | 37.2 |
SC50-6 | 8 | 10 | 12.4 | 18.2 | 44 |
SC50-10 | 10 | 10 | 12.4 | 18.5 | 44 |
SC50-12 | 12 | 10 | 12.4 | 18.5 | 44 |
SC50-14 | 14 | 10 | 12.4 | 21 | 52 |
SC50-16 | 16 | 10 | 12.4 | 21.2 | 52 |
SC70-8 | 8 | 11.5 | 14.5 | 21.2 | 51 |
SC70-10 | 10 | 11.5 | 14.5 | 21.2 | 51 |
SC70-12 | 12 | 11.5 | 14.5 | 21.2 | 51 |
SC70-14 | 14 | 11.5 | 14.5 | 21.2 | 51 |
SC70-16 | 16 | 11.5 | 14.5 | 23 | 54 |
SC95-8 | 8 | 14 | 17 | 25 | 55 |
SC95-10 | 10 | 14 | 17 | 25 | 55 |
SC95-12 | 12 | 14 | 17 | 25 | 55 |
SC95-14 | 14 | 14 | 17 | 25 | 58 |
SC95-16 | 16 | 14 | 17 | 25 | 58 |
SC120-8 | 8 | 15 | 19 | 28 | 60.5 |
SC120-10 | 10 | 15.2 | 18.9 | 27.8 | 62.8 |
SC120-12 | 12 | 15.2 | 18.9 | 27.8 | 62.8 |
SC150-12 | 12 | 17.4 | 21 | 31 | 68 |
SC150-14 | 14 | 17.4 | 21 | 31 | 68 |
SC150-16 | 16 | 17.4 | 21 | 31 | 68 |
SC185-12 | 12.2 | 18.4 | 22.8 | 34 | 75 |
SC185-14 | 14.2 | 18.4 | 22.8 | 34 | 75 |
Type | Hole diameterΦ (mm) | Inner diameter (mm) | Outer diameter (mm) | Width (mm) | Length (mm) |
SC1.5-4 | 4 | 2.5 | 3.5 | 6.5 | 18 |
SC1.5-5 | 5 | 2.5 | 3.5 | 7.5 | 18 |
SC1.5-6 | 6 | 2.5 | 3.5 | 9 | 18 |
SC2.5-4 | 4 | 2.8 | 4 | 6.5 | 19.5 |
SC2.5-5 | 5 | 2.8 | 4 | 7.2 | 19.5 |
SC2.5-6 | 6 | 2.8 | 4 | 9.5 | 19.5 |
SC4-4 | 4 | 3.7 | 5 | 7 | 20 |
SC4-5 | 5 | 3.7 | 5 | 7.5 | 20 |
SC4-6 | 6 | 3.7 | 5 | 11 | 20 |
SC4-8 | 8 | 3.7 | 5 | 11 | 20 |
SC6-5 | 5 | 4.8 | 6 | 8 | 24.5 |
SC6-6 | 6 | 4.8 | 6 | 9 | 24.5 |
SC6-8 | 8 | 4.8 | 6 | 10.5 | 24.5 |
SC10-6 | 6 | 5.2 | 6.5 | 10 | 26 |
SC10-8 | 8 | 5.2 | 6.5 | 11.5 | 26 |
SC10-10 | 10 | 5.2 | 6.5 | 14.2 | 26 |
SC16-6 | 6 | 6.2 | 8 | 12 | 31 |
SC16-8 | 8 | 6.2 | 8 | 12 | 31 |
SC16-10 | 10 | 6.2 | 8 | 13 | 31 |
SC16-12 | 12 | 7.2 | 9 | 16.8 | 36 |
SC25-6 | 6 | 7.2 | 9 | 13.2 | 33 |
SC25-8 | 8 | 7.2 | 9 | 13.2 | 33 |
SC25-10 | 10 | 7.2 | 9 | 13.2 | 33 |
SC25-12 | 12 | 7.2 | 9 | 17 | 33 |
SC35-6 | 6 | 8.5 | 10.5 | 15.5 | 37.2 |
SC35-8 | 8 | 8.5 | 10.5 | 15.5 | 37.2 |
SC35-10 | 10 | 8.5 | 10.5 | 15.5 | 37.2 |
SC35-12 | 12 | 8.5 | 10.5 | 15.5 | 37.2 |
SC50-6 | 8 | 10 | 12.4 | 18.2 | 44 |
SC50-10 | 10 | 10 | 12.4 | 18.5 | 44 |
SC50-12 | 12 | 10 | 12.4 | 18.5 | 44 |
SC50-14 | 14 | 10 | 12.4 | 21 | 52 |
SC50-16 | 16 | 10 | 12.4 | 21.2 | 52 |
SC70-8 | 8 | 11.5 | 14.5 | 21.2 | 51 |
SC70-10 | 10 | 11.5 | 14.5 | 21.2 | 51 |
SC70-12 | 12 | 11.5 | 14.5 | 21.2 | 51 |
SC70-14 | 14 | 11.5 | 14.5 | 21.2 | 51 |
SC70-16 | 16 | 11.5 | 14.5 | 23 | 54 |
SC95-8 | 8 | 14 | 17 | 25 | 55 |
SC95-10 | 10 | 14 | 17 | 25 | 55 |
SC95-12 | 12 | 14 | 17 | 25 | 55 |
SC95-14 | 14 | 14 | 17 | 25 | 58 |
SC95-16 | 16 | 14 | 17 | 25 | 58 |
SC120-8 | 8 | 15 | 19 | 28 | 60.5 |
SC120-10 | 10 | 15.2 | 18.9 | 27.8 | 62.8 |
SC120-12 | 12 | 15.2 | 18.9 | 27.8 | 62.8 |
SC150-12 | 12 | 17.4 | 21 | 31 | 68 |
SC150-14 | 14 | 17.4 | 21 | 31 | 68 |
SC150-16 | 16 | 17.4 | 21 | 31 | 68 |
SC185-12 | 12.2 | 18.4 | 22.8 | 34 | 75 |
SC185-14 | 14.2 | 18.4 | 22.8 | 34 | 75 |
